Summary

Nearly two years ago, we shared a blog post on building custom container images for CloudNativePG. Since then, the container ecosystem has evolved significantly—one notable development being the introduction of Docker Bake.

Docker Bake simplifies image builds using a straightforward configuration file, and it’s now our recommended approach for building CloudNativePG images.

In this post, we’ll walk through a simple baking recipe to create a custom container image. With Bake, you can also easily build multiple images in parallel.

Ingredients

• A Bake file, using the one provided in the CloudNativePG repository as a base.
• A second, local Bake file to override the base configuration—this lets you apply your custom changes and build the container images accordingly.

Instructions

Step 1: Prepare local Bake file

To build a custom image we add the following content in a local file with name bake.hcl:

extensions = [
  "pgvector",
]
target "myimage" {
  dockerfile-inline = <<EOT
ARG BASE_IMAGE="ghcr.io/cloudnative-pg/postgresql:16.9-standard-bookworm"
FROM $BAS_EIMAGE AS myimage
ARG EXTENSIONS
USER root
RUN apt-get update && \
    apt-get install -y --no-install-recommends $EXTENSIONS && \
    apt-get purge -y --auto-remove -o APT::AutoRemove::RecommendsImportant=false && \
    rm -rf /var/lib/apt/lists/* /var/cache/* /var/log/*
USER 26
EOT

  matrix = {
    tgt = [
      "myimage"
    ]
    pgVersion = [
      "16.9",
      "17.5",
    ]
  }
  name = "postgresql-${index(split(".",cleanVersion(pgVersion)),0)}-standard-bookworm"
  target = "${tgt}"
  args = {
    BASE_IMAGE = "ghcr.io/cloudnative-pg/postgresql:${cleanVersion(pgVersion)}-standard-bookworm",
    EXTENSIONS = "${getExtensionsString(pgVersion, extensions)}",
  }
}

There are a few important points to highlight:

• The extensions variable is a list of extensions that we want to include in the image. In our recipe we are using pgvector, but you can add others as needed.
• The dockerfile-inline variable contains our Dockerfile definition, which cannot be used remotely. We will explain why later.
• The target and the tgt values share the same name, but you can use any name you prefer.
• The pgVersion variable is a list specifying the PostgreSQL version(s) in MAJOR.MINOR format.
• The name field is used to identify individual entries in the matrix we’ve defined.
• The args variable contains the arguments passed to the Dockerfile—more on this later.
• The getExtensionsString() function is inherited from the base Bake file mentioned in the Ingredients section

Step 2: Build the image

We can now build the image using the following command:

docker buildx bake -f docker-bake.hcl -f cwd://bake.hcl "https://github.com/cloudnative-pg/postgres-containers.git" myimage

This will build the image for the bake matrix we previously created, and will try to push the image to the registry at localhost:5000, which is the default registry defined for testing environments in the parent Bake file. Let’s explain the full command:

As outlined in the Bake documentation on remote definitions, you can use a remote Bake file that includes functions and default targets, then attach a local Bake file to override any default values as needed.

In the command above, -f cwd://bake.hcl is the local file that we created in Step 1, and -f docker-bake.hcl is the remote file in the git repo, that we’re using to build the image.

You can explore more about all the content generated and used inside the Bake file by appending the --print flag, as in the following command:

docker buildx bake -f docker-bake.hcl -f cwd://bake.hcl "https://github.com/cloudnative-pg/postgres-containers.git" myimage --print

Step 3: Push the image to a registry

Now you just need to push the image to a registry. You can do this by using the following command:

registry=your/registry:5000 docker buildx bake -f docker-bake.hcl -f cwd://bake.hcl "https://github.com/cloudnative-pg/postgres-containers.git" myimage --push

The previous command will push the images in the following format: your/registry:5000/postgresql-testing:17-standard-bookworm. Using the --print flag you can explore the full list of tags created that are in the parent Bake file.

Step 4: Serve the image

You can now use the image that we’ve built for your clusters.

Deep dive into the Bake and Dockerfile

The simplicity of Bake to do even more stuff is amazing, and allows you to create custom images easily.

Bake file

The magic starts with our postgres-containers repository, where we have a docker-bake.hcl file that is being used to build the images for the CloudNativePG project. It’s the base for our custom Bake file.

The docker-bake.hcl file contains a lot of functions that are used to build the images. One of them is the getExtensionsString(). This function, given the list of extensions we provided, will return a string of the extensions with the correct package name for a Debian-based distribution, in our case, Debian Bookworm. For example, the pgvector extension will be translated into postgresql-16-pgvector, which is the name of the package for pgvector extensions for PostgreSQL 16 in the Debian Bookworm distribution.

When we add elements to, for example, the args variable, those elements are processed by the Docker bake command, and will be merged, meaning that the new elements will be added, and the existing ones will be overwritten.

Dockerfile file

The Dockerfile is defined as a heredoc string due to Bake’s limitation in overriding a remote Dockerfile with a local one. However, this approach still lets us modify the FROM directive, allowing us to base our image directly on the CloudNativePG images and add only the extensions we need—without rebuilding everything.

Making your images for specific architectures

By default, images are built for both amd64 and arm64 architectures, which is the recommended setup for most users. However, if you want to build images only for one specific architecture, saving some space, you can override the platforms variable in your local Bake file.

platforms = ["linux/amd64"]

If you’d like to build everything into your own repository while managing the same tags, that’s also possible. We may cover that in a future post.
