Main Concepts

important

Before proceeding, make sure to review the following sections of the CloudNativePG documentation:

The Barman Cloud Plugin enables hot (online) backups of PostgreSQL clusters in CloudNativePG through barman-cloud, supporting continuous physical backups and WAL archiving to an object store—without interrupting write operations.

It also supports both full recovery and Point-in-Time Recovery (PITR) of a PostgreSQL cluster.

The Object Store​

At the core is the ObjectStore custom resource (CRD), which acts as the interface between the PostgreSQL cluster and the target object storage system. It allows you to configure:

  • Authentication and bucket location via the .spec.configuration section
  • WAL archiving settings—such as compression type, parallelism, and server-side encryption—under .spec.configuration.wal
  • Base backup options—with similar settings for compression, concurrency, and encryption—under .spec.configuration.data
  • Retention policies to manage the life-cycle of archived WALs and backups via .spec.configuration.retentionPolicy

WAL files are archived in the wals directory, while base backups are stored as tarballs in the base directory, following the Barman Cloud convention.

The plugin also offers advanced capabilities, including backup tagging and extra options for backups and WAL archiving.

tip

For details, refer to the API reference for the ObjectStore resource.

Integration with a CloudNativePG Cluster​

CloudNativePG can delegate continuous backup and recovery responsibilities to the Barman Cloud Plugin by configuring the .spec.plugins section of a Cluster resource. This setup requires a corresponding ObjectStore resource to be defined.

important

While it is technically possible to reuse the same ObjectStore for multiple Cluster resources within the same namespace, it is strongly recommended to dedicate one object store per PostgreSQL cluster to ensure data isolation and operational clarity.

The following example demonstrates how to configure a CloudNativePG cluster named cluster-example to use a previously defined ObjectStore (also named cluster-example) in the same namespace. Setting isWALArchiver: true enables WAL archiving through the plugin:

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: cluster-example
spec:
  # Other cluster settings...
  plugins:
    - name: barman-cloud.cloudnative-pg.io
      isWALArchiver: true
      parameters:
        barmanObjectName: cluster-example

Backup of a Postgres Cluster​

Once the object store is defined and the Cluster is configured to use the Barman Cloud Plugin, WAL archiving is activated immediately on the PostgreSQL primary.

Physical base backups are seamlessly managed by CloudNativePG using the Backup and ScheduledBackup resources, respectively for on-demand and scheduled backups.

To use the Barman Cloud Plugin, you must set the method to plugin and configure the pluginConfiguration section as shown:

[...]
spec:
  method: plugin
  pluginConfiguration:
    name: barman-cloud.cloudnative-pg.io
  [...]

With this configuration, CloudNativePG supports:

  • Backups from both primary and standby instances
  • Backups from designated primaries in a distributed topology using replica clusters
tip

For details on how to back up from a standby, refer to the official documentation: Backup from a standby.

important

Both backup and WAL archiving operations are executed by sidecar containers running in the same pod as the PostgreSQL Cluster primary instance—except when backups are taken from a standby, in which case the sidecar runs alongside the standby pod. The sidecar containers use a dedicated container image that includes only the supported version of Barman Cloud.

Recovery of a Postgres Cluster​

In PostgreSQL, recovery refers to the process of starting a database instance from an existing backup. The Barman Cloud Plugin integrates with CloudNativePG to support both full recovery and Point-in-Time Recovery (PITR) from an object store.

Recovery in this context is not in-place: it bootstraps a brand-new PostgreSQL cluster from a backup and replays the necessary WAL files to reach the desired recovery target.

To perform a recovery, define an external cluster that references the appropriate ObjectStore, and use it as the source in the bootstrap section of the target cluster:

[...]
spec:
  [...]
  bootstrap:
    recovery:
      source: source
  externalClusters:
  - name: source
    plugin:
      name: barman-cloud.cloudnative-pg.io
      parameters:
        barmanObjectName: cluster-example
        serverName: cluster-example
  [...]

The critical element here is the externalClusters section of the Cluster resource, where the plugin stanza instructs CloudNativePG to use the Barman Cloud Plugin to access the object store for recovery.

This same mechanism can be used for a variety of scenarios enabled by the CloudNativePG API, including:

  • Full cluster recovery from the latest backup
  • Point-in-Time Recovery (PITR)
  • Bootstrapping replica clusters in a distributed topology
tip

For complete instructions and advanced use cases, refer to the official Recovery documentation.
